Pneumatic Hand Held Concrete Floor Scabbler Multiple Tungsten Heads

Pneumatic Hand Held Concrete Floor Scabbler Multiple Tungsten Heads

  • Highlight

    Hand Held Concrete Floor Scabbler

    ,

    Pneumatic Concrete Floor Scabbler

    ,

    Multiple Tungsten Heads Concrete Scabbler

  • Width Mm
    31-100
  • Air Consumption L/m
    500-900
  • HS Code
    8430610000
  • Moving Type
    Mobile
  • Transport Package
    Wooden Box
  • Condition
    New
  • After-sales Service
    Tracking Guidance & Service
  • Warranty
    One Year
  • Place of Origin
    China
  • Brand Name
    ZHONGTUO
  • Certification
    CE; ISO
  • Minimum Order Quantity
    1PC
  • Packaging Details
    Wooden Case
  • Delivery Time
    7-15Days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram

Pneumatic Hand Held Concrete Floor Scabbler Multiple Tungsten Heads

Pneumatic Hand-Held Concrete Floor Scabbler Multiple Tungsten Heads



Description of Concrete Floor Scrabbler



Hand-Held Concrete Floor Scrabbler is a tool similar to a "chopping axe" that treats the completed main structural surface so that the construction surfaces of the two construction stages are firmly bonded. Usually, the chisel machine is used in the cast-in-place concrete structure. After the cast-in-place slab is poured, the chisel should be chiseled, and the next layer of pouring should be carried out to make the concrete bond firmly.



Concrete Floor Scrabbler Technical Parameter



Model ZT-1A ZT-2A ZT-3A
Width mm 31 69 100
Air consumption l/m 500 700 900
Efficiency m2/h 3-10 3-15 3-20
Chiseling depth mm 1-3 1-3 1-3





Pneumatic Hand Held Concrete Floor Scabbler Multiple Tungsten Heads 0

Application field of Hand-Held Concrete Floor Scrabbler


1. The surface of the bridge deck is treated with chisel hair.
2. The beam surface of the high-speed railway box girder (prefabricated beam) is chiseled for waterproof treatment.
3. Concrete chisel hair on the bridge side, bridge end face, beam side, and beam end face.
4. Remove ground coating, paint, and various traffic markings.
5. Clean and remove airport road markings, airstrip tire brake marks, etc., and regain a rough surface with a high friction coefficient.
6. Surface treatment of cement asphalt pavement, highway bridge deck, bridge staggered platform, epoxy resin wear-resistant ground, etc.
7. Construction on the micro-surface of the road, chisel and remove the original old road surface, and prepare for the slurry seal
