Technical parameter of Handheld Concrete Floor Grinder Polishing Machine
Model |
12T-540
|
12T-640
|
Voltage
|
220V | 220V |
Phase
|
1/3Phrase | 1/3Phrase |
Power
|
4KW(5ph) | 7.5KW(5ph) |
Frequency
|
50/60HZ | 50/60HZ |
Working width
|
540mm | 630mm |
Disc quantity
|
6 | 12 |
Rotating speed
|
1000-1800rpm | 1000-1800 |
Water tank volume
|
36L | 60L |
Weight
|
155kg | 290kg |
Advantages of Handheld Concrete Floor Grinder Polishing Machine
1, When do some edge grinding, shroud sections can be taken off ;
2,180T turn its head right up to the wall , grinding the side of the wall;
3, Foldable handle for easy transportation.
Handheld Concrete Floor Grinder Polishing Machine Notices
1. If dry grinding, please connect the vacuum cleaner and connect to the suction port to ensure that the suction pipe has no air leakage. If wet grinding, be sure to full fill the floor with water. Do not only wet the floor in order to reduce dust, so that the resistance during the flooding process is abnormal and the motor load is overloaded.
2. Turn on the start switch and run from low speed to high speed to see if the machine is running smoothly. The speed is adjusted according to the ground conditions, and the general condition is 800-1800 rpm. Remember not to polish at low speed, especially on extremely poor ground. Low speed may work, causing the motor to overheat and burn out.
Application fields of Handheld Concrete Floor Grinder Polishing Machine
1. Floor grinding machine is mainly used for leveling, grinding, and polishing cement floors, terrazzo floors, aggregate, granite, etc.
2. Grinding of epoxy intermediate layer; smooth rough surface or trowel marks.
3. Treatment of the coated surface, removal of surface adhesions, and coating defects.
4. Remove the defects on the surface of the mortar and level the raised plaques.
5. Remove paint, polyurethane, epoxy resin, etc. from the floor surface.
6. Cleaning, waxing, and polishing hardened floors.
Our company independently produces floor grinding machines, grinding machines, polishing machines, milling machines, vacuum cleaners, and other floor machinery. At the same time, we provide high-quality accessories sales services to help floor builders complete groundwork projects efficiently, with high quality, and easily.
