Durable 250mm Concrete Asphalt Floor Grooving Scarifier Milling Machine

Durable 250mm Concrete Asphalt Floor Grooving Scarifier Milling Machine

  • Highlight

    Electric Floor Milling Machine

    ,

    Concrete Asphalt Floor Scarifier

    ,

    250mm Floor Grinder Machine

  • Dimension
    1100*800*1000mm
  • Dust Collector Capacity
    1000m³/h
  • Grinding Disc Diameter
    400mm
  • Grinding Disc Material
    Diamond
  • Grinding Disc Quantity
    2
  • Grinding Disc Speed
    1800rpm
  • Grinding Disc Thickness
    10mm
  • Grinding Wheel Diameter
    400mm
  • Grinding Wheel Material
    Diamond
  • Grinding Wheel Speed
    1800rpm
  • Power
    Electric
  • Power Source
    AC
  • Product Name
    Floor Grinder Machine
  • Voltage
    220V/380V
  • Weight
    200kg
  • Place of Origin
    CN
  • Brand Name
    ZT

Durable 250mm Concrete Asphalt Floor Grooving Scarifier Milling Machine


Introducing the Durable 250mm Concrete Asphalt Floor Grooving Scarifier Milling Machine, a high-efficiency device designed for removal of ground coating, paint, and a variety of road markings. This scarifying machine is a light motor drive ground milling machine with a powerful 7.5kw kilowatts Y132M-4 variable speed motor as the driving force. Simple operation, easy maintenance, and easy movement are some of the features of this machine. The forward cutting working principle of the machine enables the cutting of ground material quickly. Unlike large-scale milling machines' anti-cutting principle, the small milling machine relies on the positive high-speed rotation of the milling drum, shaking six groups of hard tungsten steel alloy blades on the milling cutter shaft. The use of tungsten steel alloy teeth on the alloy blade breaks and grounds the ground material, achieving surface milling effect. This concrete scarifier machine is mainly used to remove damaged ground and old floor surfaces that require renovation. With its quality, durability, and unlimited business opportunities, Durable 250mm Concrete Asphalt Floor Grooving Scarifier Milling Machine is a must-have for every professional seeking high efficiency and precision.


Description:
1 simple operation, high efficiency!
2 with easy maintenance, power, easy to move and so on
3 to remove the ground coating, paint, a variety of road marking;
4 damaged ground, the need for renovation of the plot, remove the old floor surface;
5 into the quality of heaven and earth, bring unlimited business opportunities



scarifying machine is a light motor drive ground milling machine to 7.5kw kilowatts Y132M-4 variable speed motor as the driving force, the use of forward cutting the working principle, can quickly cut the ground material! Working principle: Unlike the large-scale milling machine's anti-cutting principle, the small milling machine relies on the positive high-speed rotation of the milling drum, so as to shake the six groups of hard tungsten steel alloy blades on the milling cutter shaft. , The use of alloy blade on the tungsten steel alloy teeth to break and ground the ground material, so as to achieve the effect of surface milling;





use:
concrete scarifier machine Mainly used for highway, urban roads, airports, freight yard and other asphalt concrete surface of the excavation renovation, can also be used to remove the road package, oil waves, textures, rutting and other defects can also be used to excavate pits and ditch Groove, and the cement road surface of the hair and the surface of the wrong level of milling.





parameters:



Technical project model:WC-200G model WC-255G
Power configuration Three-phase asynchronous motor / 5.5KW (CW200D)
Honda GX270 Gasoline Engine / 13HP (WC200F)
Three-phase asynchronous motor / 7.5KW (CW255D)
Honda GX270 Gasoline Engine / 13HP (WC255F)
Number of knife shafts 6 root 6 root
Number of blades 78 pieces (6 teeth) 108 pieces (6 teeth)
Bearing seal form Sealed (maintenance-free) Sealed (maintenance-free)
A milling width 200mm 250mm
A milling depth 3mm-5mm 3mm-5mm
weight 90kg 115kg
Long × wide × high 1125×500×1125mm 1125×500×1125mm
Hourly work efficiency 150 square 170 square
Walking wheel 4 only 4 only
Air damping tube 2 only 2pc
Counterweight   25kg(standard)





Concrete Floor Grinder Riding Trowel Machine
Durable 250mm Concrete Asphalt Floor Grooving Scarifier Milling Machine 0Durable 250mm Concrete Asphalt Floor Grooving Scarifier Milling Machine 1Durable 250mm Concrete Asphalt Floor Grooving Scarifier Milling Machine 2Durable 250mm Concrete Asphalt Floor Grooving Scarifier Milling Machine 3Durable 250mm Concrete Asphalt Floor Grooving Scarifier Milling Machine 4
