15KW 10Mpa High Pressure Injection Grout Pump Concrete Delivery Pump

High Pressure Injection Grout Pump Concrete Delivery Machine

Introduction of Injection Grout Pump Concrete Delivery Machine

A concrete delivery pump, also known as a concrete pump, consists of a pump body and delivery pipe. It is a machine that uses pressure to transport concrete along the pipeline continuously. It is mainly used in housing construction, bridge, and tunnel construction, mainly divided into gate valve concrete pump and S valve concrete pump. The other is to install the pump body on the chassis of the car, and then equip it with a retractable or inflection boom to form a pump truck.

Technical Parameter of Concrete Delivery Pump

Features of High-pressure Cement Grouting Pump

1. Adopt full hydraulic design, the system hydraulic pressure is safe and reliable, and the complicated electrical control system is reduced. The failure rate is greatly reduced, and the system runs stably.
2. It has the function of an anti-pump, which is beneficial to eliminate the blockage fault in time.
3. Adopt an advanced s-pipe distribution valve, which can automatically compensate for the wear gap, and has good sealing performance.
4. Wear-resistant alloy glass and cutting ring for long service life.
5. The hydraulic pipes are optimized by American experts, and the unique air-cooled and water-cooled design can effectively control the temperature and prolong the service life of hydraulic components.
6. Centralized lubrication system to ensure effective lubrication during machine operation.
7. The humanized design of the product makes the operation more convenient and maintenance easier.

Operating Specifications of Injection Grouting Pump

1. The towed concrete pump can be towed by motor vehicles, but shall not carry any cargo, and the towing speed shall not exceed 8km/h;
2. The pressure of the concrete grouting pump and each safety valve of the hydraulic system shall meet the requirements of the manual, and the user shall not adjust or change it;
3. Antifreeze measures should be taken for the construction of concrete transfer pumps in cold seasons;
4. During construction in hot seasons, the concrete pump should prevent the oil temperature from being too high. When the temperature reaches 70℃, stop the operation or take other measures to cool down;
5. After pumping concrete, clean the hopper, S valve, concrete cylinder, and conveying pipeline in time. After the pump is cleaned, the pressure of the accumulator should be released, the power supply should be cut off, and the switches should be in the stop or disconnected position;
6. Staff are not allowed to climb or ride on the pipeline, and should absolutely avoid it when working at heights;

Concrete Pump Applications

1. Pumping wet-mixed mortar for high buildings and secondary structure construction.

2. KS series concrete pump is widely used for secondary construction filling, reinforcement grouting, fullback grouting, and bolt supporting in floor heating engineering, roofing, high-rise building walls, reservoirs, hydropower stations, ports, docks, foundation treatment, soft foundation, tunnels, subways, mining construction, etc.

Entire Service

We would provide customers with a one-year warranty, during processing, if customers have any problems with installation and use, we have professionals to provide online text, voice, or video communication services for them.
