7.5KW High Performance Portable Slurry Pump BW150 Horizontal Mud Pump

High Performance Portable Slurry Bw150 Mud Pump

Working Performance of Bw150 Portable Mud Pump

1. Bw150 Mud Pump of hydraulic grouting pumps are professional grouting equipment, which can realize single liquid grouting and double liquid grouting.

2. Inflammable and explosive construction sites such as coal mines, this series of hydraulic grouting motors use explosion-proof motors and can also be used safely.

3. There is an anti-seismic pressure gauge in the hydraulic system, which can accurately reflect the working state of the pump.

4. This series of hydraulic grouting pumps can also be used as a clean water pump, sewage pump, and mud pump.

Technical parameters of Bw Mud Pumps

Details of BW 150 Mud Pump

1. BW150 grouting pump is a horizontal three-cylinder reciprocating single-acting piston pump, which is mainly used for grouting construction of roads, bridges, dams, mines, and high-rise buildings.

2. Eight different working pressures and flow rates can be changed, and it is suitable for conveying flushing fluid (mud, water, saponification fluid) to the borehole in geological core drilling engineering, and diamond drilling with a diameter of fewer than 1500 meters. It can also be used for medium and low-pressure, cement slurry injection, The pump consumes less energy, operates flexibly, and is easy to maintain.

Maintenance of Bw Series Mud Pump

1. Mud pumps and other mechanical equipment should be inspected and maintained on a scheduled and timely basis to find and address problems ahead of time, in order to avoid an unscheduled shutdown. 2. The worker should attend to the size of the sediment particles; if large particles are found, the mud pump parts should be checked frequently for wear, to see if they need to be repaired or replaced. The wearing parts for mud pumps include pump casing, bearings, impeller, piston, liner, etc.

3. Advanced anti-wear measures should be adopted to increase the service life of the wearing parts, which can reduce the investment cost of the project, and improve production efficiency. At the same time, wearing parts and other mud pump parts should be repaired rather than replaced when possible.
