4-7L\M Flow Rebar Extrusion Press Machine Steel Bar Cold Extruding Machine
-
Highlight
7L\M Rebar Extrusion Press Machine
,4 L\M Rebar Extrusion Press Machine
,Steel Bar Cold Extruding Machine
-
Flow4-7L\m
-
Power4-7.5KW
-
Voltage380V
-
Warranty1 Year
-
CertificationCe,ISO
-
ColorCustomized
-
Weight110-200kg
-
After-sales ServiceTracking Guidance & Service
-
Place of OriginChina
-
Brand NameZHONGTUO
-
CertificationCE; ISO
-
Minimum Order Quantity1
-
PriceUSD1500-2500/PC
-
Packaging DetailsWooden Case
-
Delivery Time7-15Days
-
Payment TermsL/C, D/A, D/P, T/T, Western Union, MoneyGram
4-7L\M Flow Rebar Extrusion Press Machine Steel Bar Cold Extruding Machine
Rebar Extrusion Press Machine Steel Bar Cold Extruding Machine
Product Description of Steel Bar Cold Extrusion Machine
Cold extrusion machine is to need to pick up two reinforced in cold extrusion sleeve, and through the cold extrusion machine to squeeze of steel sleeve, with reinforced tightly, connect the two root reinforcement for the integration of equipment.
Construction steel cold extrusion machine is currently in construction projects, construction of reinforced concrete structures, high-rise frame buildings, roads, railways, tunnels, Bridges, airport construction, flood control levees, seismic shock construction, Marine breakwater dam etc for all kinds of building cold extrusion bar connection application.
| Product Name | 32 steel bar cold extrusion machine | 40 steel bar cold extrusion machine | Large one-time compression molding |
| Voltage | 380V | 380V | 380V |
| Motor Power | 4KW | 4KW | 7.5KW |
| Extrusion diameter | 16-32mm | 36-40mm | 16-32mm |
| Clamp weight | 35KG | 45KG | 100KG |
| Pump station weight | 75KG | 75KG | 100KG |
| Weight | 110KG | 120KG | 200KG |
| Tubing length (can be extended) Maximum | 5m | 5m | 5m |
| Pressure | 63mpa | 63mpa | 63mpa |
| Flow | 4L/min | 4L/min | 7L/min |
| Hydraulic Oil Type | add 32 anti-wear hydraulic oil in winter, and 46 anti-wear hydraulic oil in other seasons. | ||
Technical advantages of Steel Bar Cold Extrusion Machine
1. Good connection reliability and 100% connection rate.
2. Quick construction speed.
3. The construction is not affected by the weather.
4. Can connect reinforcing bars in all directions.
5. The inspection is convenient, and only the extrusion trace can be measured to determine whether it is qualified or not.
Product Application of Steel Bar Cold Extrusion Machine
1. Stable connection process, convenient construction, easy operation.
2. Joint's performance is reliable, quality is easy to check and control, and not affected by the welding performance of the rebar.
3. It is not affected by climate change, and can be all-weather operations.
4. Fast extrusion splicing speed, high work efficiency, in general, it can increase 3-5 times on work efficiency compared with electric arc welding joint.
5. It is suitable for various specifications, especially splicing of large-diameter rebar, and suitable for splicing of rebar in any position and direction (horizontal, vertical, surrounded by dense or diagonal).
6. No naked fire in construction, eliminate the fire hazards, can be operated in Inflammable, explosive construction sites, etc.
7. The extrusion equipment is small volume, light weight, flexible operation, and used with a balancer, one person can move up and down by hand to extrusion rebar conveniently.
8. Using cold extrusion splicing can remove lots of welding equipments on construction site and a large amount of acetylene, oxygen, etc. Compared with lap welding, can save lots of steel, and the comprehensive economic and technical effect is remarkable.
Entire Service
We would provide customers with a one-year warranty, during processing, if customers have any problems with installation and use, we have professionals to provide online text, voice, or video communication services for them.
Our products are sold all over the world, you can rest assured.
