Cold Squeezing Rebar Processing Machine Rebar Extrusion Press Machine
-
Highlight
Cold Squeezing Rebar Processing Machine
,Rebar Processing Machine 7.5KW
,4KW Rebar Extrusion Press Machine
-
Flow4-7L/m
-
Power4-7.5KW
-
Voltage380V
-
Warranty1 Year
-
CertificationCe,ISO
-
ColorCustomized
-
Weight110-200kg
-
After-sales ServiceTracking Guidance & Service
-
Place of OriginChina
-
Brand NameZHONGTUO
-
CertificationCE; ISO
-
Minimum Order Quantity1
-
PriceUSD1500-2500/PC
-
Packaging DetailsWooden Case
-
Delivery Time7-15Days
-
Payment TermsL/C, D/A, D/P, T/T, Western Union, MoneyGram
Cold Squeezing Rebar Processing Machine Rebar Extrusion Press Machine
Cold Squeezing Rebar Processing Machine Rebar Extrusion Press Machine
Product Description of Steel Bar Cold Extrusion Machine
Steel bar cold extrusion press machine is a kind of steel bar processing equipment, which is mainly used for the connection of various steel bars in some engineering constructions, such as reinforced concrete structure construction, high-rise frame construction, ordinary ways, high ways, ordinary railways, high-speed railways, tunnels, bridges, airport construction, flood control dams, earthquake-resistant buildings, marine breakwater dams, etc. The rebar cold extrusion press machine manufactured by Deleixi Machinery is suitable for machining steel bars with diameters of 16 to 32mm or we can customize it for you according to your needs.
| Product Name | 32 steel bar cold extrusion machine | 40 steel bar cold extrusion machine | Large one-time compression molding |
| Voltage | 380V | 380V | 380V |
| Motor Power | 4KW | 4KW | 7.5KW |
| Extrusion diameter | 16-32mm | 36-40mm | 16-32mm |
| Clamp weight | 35KG | 45KG | 100KG |
| Pump station weight | 75KG | 75KG | 100KG |
| Weight | 110KG | 120KG | 200KG |
| Tubing length (can be extended) Maximum | 5m | 5m | 5m |
| Pressure | 63mpa | 63mpa | 63mpa |
| Flow | 4L/min | 4L/min | 7L/min |
| Hydraulic Oil Type | add 32 anti-wear hydraulic oil in winter, and 46 anti-wear hydraulic oil in other seasons. | ||
Technical advantages of Steel Bar Cold Extrusion Machine
1. Good connection reliability and 100% connection rate.
2. Quick construction speed.
3. The construction is not affected by the weather.
4. Can connect reinforcing bars in all directions.
5. The inspection is convenient, and only the extrusion trace can be measured to determine whether it is qualified or not.
What You Should Be Careful of When Using The Machine:
- The rust, sand, oil and other debris of the steel bar must be cleaned up.
- Mark the ends of the steel bars to be connected with paint.
- For a few steel bars that can’t be inserted into the couplers after exceeding tolerance, please grind the longitudinal at the end by grinding the wheels in advance.
- Cold extrusion rebar couplers should be stored according to different specifications to prevent the interaction between different diameters of steel.
Entire Service
We would provide customers with a one-year warranty, during processing, if customers have any problems with installation and use, we have professionals to provide online text, voice, or video communication services for them.
Our products are sold all over the world, you can rest assured.
