Hydraulic Diesel Rock Splitting Equipment 250mm 350mm 450mm Length For Quarry

Technical Parameter of Powerful Splitter Machine

Working Theory of Powerful Splitter Machine

The wedges are placed into a drilled hole. When a splitter is operated, the power pack produces high-pressure oil to drive the piston of the splitter cylinder which in turn pushes the middle wedge down. The downward movements of the middle wedge force two counter wedges against the wall of the hole. When the tension increases beyond the material's tensile strength.

Step 1: Drill the holes in the rock/concrete required to split of suitable diameter and length.

Step 2: Put the wedge group of cylinders into the hole. Check the position before starting the splitter.

Step 3: Once the splitter is initiated, a crack will be developed due to the expansion of counter wedges. The cracking direction of the rock/concrete is the same as that of the splitter handle.

Advantages of Powerful Splitter Machine
1. Security: The hydraulic splitting machine uses the physical properties of hydraulic oil to be non-compressible and movable and adds static thrust to complete the task of static controllability.
2. Eco-friendly: There is no vibration, impact, noise, dust, or flying debris in the whole process.
3. Efficiency: machine completes one task within 10 -15 seconds with powerful splitting force (the rock-splitting tonnage can reach 840t), and can continue to work continuously with high efficiency.
4. Application flexibility: The splitting machine has a small volume, lightweight, and compact structure. It ensures that the application method is easy to learn, and just one person is required to operate it.

Splitting Point of Powerful Splitter Machine

The diameter of the bottom hole depends on the hydraulic rock splitter wedge assembly, and the size of the wedge assembly depends on the size of the rock on site.

The direction of the rock drilling should be perpendicular to the surface where the hole is located, the size of the hole should be adapted to the diameter of the splitting machine, and the depth of the drilling should be 200mm deeper than the insertion length of the wedge block. Splitting Insert the splitting gun into the manhole, and adjust the splitting direction as needed.

Application of Powerful Splitter Machine

The hydraulic splitting machine is mainly used for tunnel excavation, underground prospecting, and excavation of rock bases, multiple splitting of extra-large rocks, granite, flint rock, quartzite, basalt, quartz porphyry, siliceous schist, sandstone, limestone, and marble. Dolomite, sedimentary rock, granite, pyrite iron, etc.

Demolition operations in indoor and narrow sites, demolition of reinforced concrete structures/plain concrete structures, foundations, walls, old bridge piles, chimneys, cut pile heads, and secondary block demolition of thick concrete slabs.

Entire Service

We would provide customers with a one-year warranty, during processing, if customers have any problems with installation and use, we have professionals to provide online text, voice, or video communication services for them.
