Highlight
Diesel Water Well Drilling Rig Machine
,Rotary Drilling Rig Machine
,Electric Motor water well drilling machine
-
Drilling Depth100-200（m）
-
Weight362（kg）
-
ModelZSJD-100/120/150/200
-
Drilling Angle Range360（°）
-
Broken WayRotary Drill
-
Drilling Diameter120-150（mm）
-
Applicable Voltage220V/380V
-
After-sales ServiceTracking Guidance & Service
-
WarrantyOne Year
-
Place of OriginChina
-
Brand NameZT
-
CertificationCE ISO
-
Model NumberZTJD100/150/180
-
Minimum Order Quantity1PC
-
PriceUSD2500-3000/PC
-
Packaging DetailsWooden Case
-
Delivery Time7-15 Work Days
-
Payment TermsL/C, D/A, D/P, T/T, Western Union, MoneyGram
Electric Motor Diesel Water Well Drilling Rig Machine
Descriptionof Water Well Drill Machine
Diesel Small tube well drill rig machine Geotechnical hydraulic Mine Underground borehole core Water Well Drilling Rig Machine:
This machine is mainly used for geothermal drilling, farm irrigation, house yard, gardens, and water well drilling, drilling diameter is 70-300mm, and the drilling depth is 80-100m. It also can be used in minor building piling, like farmhouses or factories and so on, the drilling diameter can reach 300mm and the depth less than 10m.
Parameters of Water Well Drill Machine
| Rig model | ZSJD-100 type | Motor Power | 4000W |
| Drill pipe diameter | 4.2mm | Drilling and crushing method | Impact Rotary |
| Dimensions | 80cm*80cm*245cm | Drilling depth | 100-200M |
| Drill pipe length | 1.5m | Pump power | 2.2KW |
| Rig weight | 200KG | Drilling diameter | Within 400mm |
| Drill pipe replacement method | Thread button (automatic double thread) | Machine Height | 2 meters |
| Applicable voltage | 220V/380V | Force | 1000KG |
| Rig model | ZTJD-150 type | Motor Power | 4000W |
| Drill pipe diameter | 50mm | Drilling and crushing method | Impact Rotary |
| Dimensions | 90cm*90cm*245cm | Drilling depth | 100-200M |
| Drill pipe length | 1.5m | Pump power | 2.2KW |
| Rig weight | 250KG | Drilling diameter | Within 400mm |
| Drill pipe replacement method | Thread button (automatic double thread) | Machine Height | 2 meters |
| Applicable voltage | 220V/380V/ Gasoline / Diesel |
Force | 2000KG |
| Rig model | ZTJD-180 type | Motor Power | 4000W |
| Drill pipe diameter | 50mm | Drilling and crushing method | Impact Rotary |
| Dimensions | 100cm*100cm*245cm | Drilling depth | 100-200M |
| Drill pipe length | 1.5m | Pump power | 2.2KW |
| Rig weight | 290KG | Drilling diameter | Within 500mm |
| Drill pipe replacement method | Thread button (automatic double thread) | Machine Height | 2 meters |
| Applicable voltage | 220V/380V/ Gasoline / Diesel |
Force | 2000KG |
Features of Water Well Drill Machine
The diesel engines power the drilling rigs. The drilling diameter can reach 50-450mm. It is equipped with diamond drill bits and mud pumps for drilling with a depth of up to 150 meters. Easy to move, suitable for your soil layer, quicksand layer, a small amount of rock layer, pebbles, etc.
Application of Cheap Borehole Drilling Machine /water well drilling rig for Sale 200m:
This machine is mainly used in geothermal drilling, farm irrigation, house yard, gardens, and minor building piling, drilling diameter is 70-350mm, and the drilling depth is within 200m.
Our products are sold all over the world, you can rest assured.
