Diesel Power Station Hydraulic Rock Splitter For Large Hole Blasting Pressure Oil Pump
-
Highlight
Alloy Steel Rock Splitter Machine
,Diesel Power Station Hydraulic Rock Splitter
,Pressure Oil Pump Hydraulic Rock Splitter
-
MaterialHigh-strength Alloy Steel
-
Max Splitting Angle90°
-
Max Splitting Depth50 Cm
-
Max Splitting Force100 Tons
-
Max Splitting Frequency20 Times/min
-
Max Splitting Height20 Cm
-
Max Splitting Pressure200 Mpa
-
Max Splitting Speed2.5 M/s
-
Max Splitting Temperature100°C
-
Max Splitting Width50 Cm
-
NameRock Splitter Machine
-
PowerHydraulic
-
Size2.5 M X 1.5 M X 1.2 M
-
TypeHydraulic Splitter
-
Weight1000 Kg
-
Place of OriginCN
-
Brand NameZT
Diesel Power Station Hydraulic Rock Splitter For Large Hole Blasting Pressure Oil Pump
Introducing the Diesel Power Station Hydraulic Rock Splitter for Large Hole Blasting, a powerful and versatile tool for mining, earthwork excavation, tunneling projects, and smelting and dismantling work. Composed of a high hydraulic pump station and split rod, this hydraulic plunger rock splitter can output a force of 140-180MP ultra-high pressure oil pump station onto a hole, allowing it to split rock in a predetermined direction with a powerful force of up to 3000t.
During operation, it is critical that the hole is straight when punching and that the rod is placed inside to ensure an even force distribution and an achievable blasting effect. The tool must also be kept horizontal, straight, and facing the air side to maximize its performance.
This hydraulic rock splitter is perfect for mining of metal mines, non-metal mines, and coal mines, earthwork excavation works such as roads and bridges, houses, foundations, and reinforced concrete demolition, tunneling projects including subways, culverts, mines, underground pipelines, river management, and other projects as well as smelting and dismantling work, crushing, and dismantling various smelting furnaces.
Invest in the Diesel Power Station Hydraulic Rock Splitter for Large Hole Blasting today and enjoy a reliable, high-performance tool for all your mining, excavation, and demolishing needs.
| Model | Length(mm) | Piston | Plunger | Hole | Extension | Weight(kg) |
| Quantity | Diameter(mm) | Diameter(mm) | Length(mm) | |||
| ZT90 | 650 | 9 | 35 | 87 | 15 | 27 |
| ZT100 | 710 | 8 | 45 | 112 | 25 | 47 |
| ZT110 | 820 | 11 | 40 | 100 | 22 | 44 |
| ZT120 | 770 | 8 | 45 | 122 | 15 | 60 |
| ZT130 | 1006 | 10 | 45 | 130 | 23 | 97 |
| ZT150 | 960 | 8 | 50 | 153 | 33 | 118 |
| ZT170 | 1004 | 8 | 60 | 174 | 34 | 166 |
| ZT200 | 1285 | 8 | 70 | 200 | 32 | 291 |
Working principle
Hydraulic Plunger Rock Splitter is mainly composed of a high hydraulic pump station and split rod. The force output by the 140-180MP ultra-high pressure oil pump station acts on the hole, and the rock hydraulic splitter blasting equipment would split the rock in a predetermined direction under the (3000t) powerful force.
Notice
In operation, the hole must be straight when punching, and the rod must be placed in the hole to ensure that the rod cannot be exposed. If not, this would result in uneven force and an unachievable blasting effect. Keep the horizontal plane, be a straight line, and at the same time face the air side.
Application areas:
1. Mining of metal mines, non-metal mines, and coal mines.
2. Earthwork excavation works: roads and bridges, houses, foundations, reinforced concrete demolition, and other works.
3. Tunneling projects: subways, culverts, mines, underground pipelines, river management, and other projects.
4. Smelting and dismantling work: crushing and dismantling various smelting furnaces, kilns, refractory bricks, and carbon blocks.
A1: Equipped with different drill bits according to the application object. Rock drilling rigs are equipped with round steel drill impact hammers and rock drill bits. The soil drilling rigs require a twist drill pipe and a three-blade drill bit.
Q2: How much tonnage can a bridge jack lift??
A2: The range is from 50 to 1000 tons, depending on the application needs we have the right choice for you.
Q3: How many meters is the connection between the jack and the oil pump?
A3: The factory standard is two meters. If you need longer, we will make it for you.
Q4: What is the difference between the hydraulic oil pump?
A4: For the tension jack, it is 50 MPa 3 kW oil pump and 60 MPa 4 kW oil pump.
Q5: What kind of packages does a set of anchors have?
A5: Anchor ring, clip, anchor pad, spiral rib.
Q6: Which payment term can you accept?
A6: 100% T/T( Decide according to actual situation)
Q7: How long is the machine warranty?
A7: One year for the machine and provide technical support according to your needs.
Q8: How long will it take to arrange production?
A8: we can deliver the normal goods within 7-15 days. Other nonstandard electrical items we will deliver within 25-30 days.
Q9: Which trade term can you accept?
A9: Available trade terms: FOB, CIF, CFR, EXW, etc.
Q10: Do you provide samples? Is it free or extra?
A10: Yes, we could offer you the sample machine. But it's not free. You need to pay for the sample and the cost of the freight.
Q11: What are your terms of payment?
A11: We accept T/T, Western Union, Money Gram, Paypal, L/C, etc.
